Hubsan ACE SE R Refined GPS 9KM FPV with 4K 30fps Camera 3-axis Gimbal 37mins Flight Time Carbon Fiber RC Drone Quadcopter RTF 2 Batteries Combo
Hubsan ACE SE R Refined GPS 9KM FPV with 4K 30fps Camera 3-axis Gimbal 37mins Flight Time Carbon Fiber RC Drone Quadcopter RTF
Specifications:
| Aircraft | Dimensions | Expand:229.55 x 178 x 73.6mm Folded:118.7 x 172.5 x 67.6mm |
| Diagonal Wheelbase | 266mm | |
| Color | Carbon Fiber Black | |
| Takeoff Weight (with battery) | About 600g | |
| Hover Accuracy | Indoor:Vertical ?I 0.1m, Horizontal ?I 0.1m Outdoor:Height<5m, Vertical < Height * 0.02m, Horizontal < Height * 0.02m Height>5m, Vertical ?I 0.1m, Horizontal ?I 0.5m |
|
| Max Ascension Speed | 3m/s (N), 4m/s (S) | |
| Max Descent Speed | 1.5m/s (N), 3m/s (S) | |
| Maximum Horizontal Flying Speed | 5m/s (N), 10m/s (S) | |
| Maximum Take-off Altitude | 5000m | |
| Max Wind Speed Resistance | Level 7 wind, wind resistance mode can withstand Grade 8 wind | |
| Max Tilt Angle | 30??(S), 20??(N), 20??(F) | |
| Positioning | GPS + GLONASS, Beidou Satelite | |
| Flight Duration | Hovering for 33 minutes (Windless, measured in 2-4 meters hovering) Slow Flight Time 37 minutes |
|
| Power System | Maximum Working Current | 25A |
| Propeller | Model:Foldable & Diameter 158.6mm Color:Black |
|
| Motor | Outward Rotation Brushless Motor 1503, KV2820 |
|
| ESC | Digital ESC Brushless 20A x 4 | |
| Camera | CMOS Image Sensor | 1/2.6inch CMOS, 12 million effective pixels |
| Lens Specifications | FOV 80?? Aperture f/2.2 EFL:3.5mm Distortion:<1.5% |
|
| Focus Point | 0.5m to ?? | |
| Video Resolution | 4K:3840×2160@30fps 2.7K:2720×1530@30fps 1080P:1920×1080@30fps |
|
| Shutter Speed | 3-1/8000s | |
| Video Bitrate | 45Mbps-100Mbps | |
| Photo Format | JPEG | |
| Video Format | MP4 (H.264/MPEG-4 AVC) | |
| Portrait Mode | Support | |
| Control Method | APP, Remote Control | |
| Firmware Upgrade | OTA | |
| USB Interface | Micro-USB | |
| Supported SD Cards | MicroSD Card, U3 or Class10 above 16G/32G/64G/128G |
|
| Wireless Transmission System | Image Transmission System | SyncLeas 2 |
| Effective Range | FCC:9KM CE:<= 9KM; SRRC:<= 9KM |
|
| Band Mode | Frequency Button | |
| Transmission Delay | Within 200ms | |
| Antenna Position | Forearm Support Foot | |
| Remote Control | HT16MY | |
| Gimbal | Gimbal | HY817C |
| Stabilization | 3-Axis (tilt, roll, pan) | |
| Degree of Freedom | Triaxial | |
| Max Pitch Speed | 120??/s | |
| Mechanical Range | Pitch:-120?? to 45?? Roll:?I 35?? Yaw:?I 35?? |
|
| Flight Controller | FC Version | Third-generation Flight Controller |
| Basic Flight Mode | Wind Resistance Mode / Sports Mode / Normal Mode | |
| Altitude Hold Mode | Tof, Barometer | |
| Fixed-point | Visual Optical Flow, GPS | |
| Unlock/Lock | Outer ‘Eight’ Unlock/Lock | |
| Fill Light | Support 0.5m-5m low light environment to automatically turn on the light | |
| One Key Take-off/Landing | APP Supported??Remote Control Unsupported | |
| Headless Mode | ?| | |
| Out of Control Protection | ?| | |
| Low Battery Protection | Automatically Return to Home and Land on Low Battery | |
| Home Visual Recognition (search for drone apron) |
?| | |
| Visual Tracking | Third-generation Tracking Technology (ATVT 3.0) | |
| Waypoint Flight | ?| | |
| Flying Around | ?| | |
| Auto Drifting | ?| | |
| Intelligent Battery | Cell Balancing, Intelligent Power Estimation, Overcurrent Protection, High Temperature Protection, Overcharge Protection, Over-discharge Protection, Auto-Discharging Protection, Struggling Mode, Intelligent On-Off Control |
|
| ESC | Self-developed ESC, digital PWM | |
| Motor Stall Protection | ?| | |
| Remote Control | Color | Black |
| Wireless Transmission Solution | SyncLeas 2 | |
| Display | NO Support | |
| Operating Environment Temperature | -5 Deg.C- 50 Deg.C | |
| Effective Range | FCC:9KM CE:9KM; SRRC:9KM |
|
| Built-In Battery | 3200mAh | |
| Mode | Mode 2 (Left Hand Throttle) | |
| Buzzer | Support | |
| Support Mobile System | Android, iOS | |
| Working Time | 2.5h (Normal Flight Time) | |
| Interfaces Type | Lighting / Micro USB / Type-C | |
| Battery | Battery Type | Li-Po Battery 4S |
| Capacity | 3200 mAh 46.08Wh | |
| Standard Voltage | 3.6Vx4=14.4V | |
| Charging Limit Voltage | 4.2Vx4=16.8V | |
| Discharge Rate | 8C | |
| Charging Time | 120 minutes | |
| Weight | 230g | |
| Working Environment Temperature | -5 Deg.C- 40 Deg.C | |
| Charging Environment Temperature | 0 Deg.C- 40 Deg.C | |
| Smart Battery | Cell Balancing, Intelligent Power Estimation, Overcurrent Protection, High Temperature Protection, Overcharge Protection, Over-discharge Protection, Intelligent On-Off Control |
|
| Battery Smart Buckle | ?| | |
| Low Battery Protection | Support Turn on the battery after the power is less than 1% In order to prevent over-discharge, the battery no longer provides external power output |
|
| Struggling Mode | ?| | |
| Internal Resistance Monitoring | ?| | |
| HBLog | ?| | |
| Intelligent Diagnosis | ?| | |
| Remote Locking | ?| | |
| Online Upgrade | ?| | |
| APP | APP Name | X-Hubsan 2 |
| Mobile Device | Requirements | iOS 10.0 or higher Android 6.0 Or higher |
Features:
– Cost Effective, Cool, Reliable
– Ultra-Clear 4K 30-frame Video
– 1/2.6inch image sensor, 100Msbp video bit rate
– 9KM HD Transmission Distance
– 3-Axis Stabilized Gimbal
– Grade 8 Wind Resistance
– Intelligent Battery
– Maximum Flying Time up to 37mins
– Portrait Mode & Upward Vision Mode
Package Included:
1 x ACE SE R Drone
1 x Remote Controller
1 x Drone Battery
1 x Pair of Propellers
1 x Intelligent Charger
1 x Micro-USB Cable
1 x Micro-USB RC Cable
1 x USB Type-C RC Cable
1 x RC Cable
1 x Screwdriver
1 x Manual
Additional information
| Weight | 0.5 kg |
|---|---|
| Mode: No selection | With Storage Bag |
| Battery: No selection | Two Batteries |
