23IOD32 32CH Multifunctional RS485 Remote IO Module PLC DI-DO Expansion Board DIN Rail
Specifications:
Working voltage:DC 6.5-30V (9V 12V 24V)
Working current:8-50mA
Number of optically isolated input ports:32 (PNP input)
Number of Darlington transistor outputs:32 (ULN2803 NPN output)
Baud rate:Default 9600BPS, adjustable via jumper (1200/2400/4800/19200/38400/57600/115200BPS)
Maximum delay of MODBUS command:255 seconds
Maximum parallel devices in MODBUS command mode:64
Size (with box):215x80x30mm
Weight (with box):246g
Maximum load current per channel:300mA
Features:
1. Versatile Input and Output Configuration:This module supports 32 optically isolated input ports and 32 Darlington transistor outputs, providing flexibility for various applications.
2. RS485 Bus Control:The input ports can be used to remotely control the output ports of another board via the RS485 bus. Relevant registers need to be configured for this functionality.
3. MODBUS Command Support:The module supports two types of MODBUS commands. MODBUS Command 1 supports function codes 03, 06, and 16, while MODBUS Command 2 supports function codes 01, 02, 03, 05, 06, 15, and 16.
4. Multiple Output Modes:The default command includes a variety of output modes, including ‘open,”close,”momentary,”self-locking,”interlock,’ and ‘delay.’ These modes provide flexibility in controlling connected devices.
5. Reliable and Compact Design:With optically isolated input ports and ULN2803 NPN outputs, this module ensures reliable performance. Its compact size and lightweight construction make it convenient to integrate into various setups.
Package Include:
1?? Module Board
Additional information
Weight | 0.246 kg |
---|---|
The Type: No selection | 32CH NPN only Board, 32CH NPN with Box, 32CH PNP only Board, 32CH PNP with Box |
