WZ5012L 50V 12A 600W LED Display DC -DC Buck Converter CC CV Step-down Power Module Adjustable Voltage Regulated Power Supply
Features:
1. LCD can display input/output voltage, output current/output power/output capacity/output time;
2. Numerical control adjustment, precise and fast, step-down output, output voltage 0-50.00V arbitrarily adjusted, limit current 0-12.00A arbitrarily adjusted;
3. The output end does not burn when it is poured backwards;
4. The module can be set to turn on/off by default;
5. has a variety of software protection mechanisms, and the protection threshold is adjustable. After the module’s working parameters exceed the protection threshold, the output will be automatically turned off;
6. Using synchronous rectification technology, high conversion efficiency:efficiency is above 90%;
7. Enlarge the heat sink and install a fan to enhance heat dissipation.
Specification:
Model Number:WZ5012L
Output Power:600W
Output current:12A
Output voltage:50V
Package included:
1 x Power Supply Module
1 x LED display
Additional information
| Weight | 0.24 kg |
|---|
