30.5×30.5mm iFlight BLITZ F7 V1.1 OSD Flight Controller w/ 5V BEC Output & BLITZ E45S 45A BL_S 4In1 2-6S ESC Stack / 800mW VTX for RC Drone FPV Racing
Specifications:
Flight control+ESC
Input voltage:2-6S
Size:36.5*35mm
Installation size:30.5*30.5mm
Packing size:190*80*20mm
Packing weight:65g
Flight control technical parameters:
Firmware version:IFLIGHT_BLITZ_F722
Flight control chip:STM32 F722
OSD Firmware:IFLIGHT OSD (AT7456E)
Gyroscope:BMI270
Barometer:DPS310
Black Box:32MB
BEC:5V 2.5A
Serial port:6 optional
Motor output:8 optional
USB type:Type-C
LED strip:support
Buzzer:support
Input voltage:2-6S Lipo
Power output:5V/2.5A, 9A
Weight:7.9g
BLITZ E45S ESC technical parameters:
Input voltage:2-6S
Firmware:QH-40 16.7
Continuous current:45A
Instantaneous current:55A
MCU:BB21
Current sensor:yes scale 200
Drive signal support:DShot150/300/600MultiShot.OneShot
Weight:15g
VTX:
Transmit power:25/100/400/800mW adjustable
Working voltage:2-6S
Protocol:IRC-tramp
Antenna interface:MMCX
Channel:40CH
Output voltage:5V
Weight:7.5g
Package Included:
| Version ( Optional) | Package Included |
| Flight Controller Module | 1x BLITZ F7 Flight Controller |
| FC + ESC + VTX | 1x BLITZ F7 Flight Controller 1x BLITZ E45S 4IN1 2-6S ESC 1x Force 800mW VTX |
| FC + ESC | 1x BLITZ F7 Flight Controller 1x BLITZ E45S 4IN1 2-6S ESC |
| ESC | 1x BLITZ E45S 4IN1 2-6S ESC |
| VTX | 1x Force 800mW VTX |
Additional information
| Weight | 0.065 kg |
|---|---|
| Version: No selection | ESC, FC+ESC, Flight Controller Module, VTX |
