ESP32 CAM Development Board with OV2640 Camera Module Receiver WIFI+Digital Bluetooth Module Kit

ESP32 CAM Development Board with OV2640 Camera Module Receiver WIFI+Digital Bluetooth Module Kit
Features:
Use low-power dual-core 32-bit CPU, which can be used as an application processor.
The main frequency is up to 240MHz, and the computing power is up to 600 DMIPS
Built-in 520 KB SRAM, external 8MB PSRAM
Support UART/SPI/I2C/PWM/ADC/DAC and other interfaces
Support OV2640 and OV7670 cameras, built-in flash
Support picture WiFI upload
Support TF card
Support multiple sleep modes.
Embedded Lwip and FreeRTOS
Support STA/AP/STA+AP working mode
Support Smart Config/AirKiss one-click network configuration
Support secondary development
Specifications:
Working voltage 4.75-5.25V
SPIFlash default 32Mbit
RAM internal 520KB + external 8MB PSRAM
Wi-Fi 802.11b/g/n/e/i
Bluetooth Bluetooth 4.2BR/EDR and BLE standard
Support interface (2Mbps) UART, SPI, I2C, PWM
Support TF card, maximum support 4G
IO port 9
Serial port rate default 115200bps
Spectrum range 2400 ~2483.5MHz
Antenna form Onboard PCB antenna, gain 2dBi
Image output format:JPEG (only OV2640 support), BMP, GRAYSCALE
Packaging method DIP-16
Transmit power 802.11b:17??2dBm (@11Mbps)
802.11g:14??2dBm (@54Mbps)
802.11n:13??2dBm (@MCS7)
Receiving sensitivity CCK, 1Mbps:-90dBm
CCK, 11Mbps:-85dBm
6Mbps(1/2BPSK):-88dBm
54Mbps (3/464-QAM):-70dBm
MCS7 (65Mbps, 72.2Mbps):-67dBm
Power consumption Turn off the flash:180mA@5V
Turn on the flash and adjust the brightness to the maximum:310mA@5V
Deep-sleep:The lowest power consumption can reach 6mA@5V
Moderm-sleep:the lowest can reach 20mA@5V
Light-sleep:the lowest can reach 6.7mA@5V
Security WPA/WPA2/WPA2-Enterprise/WPS
Working temperature -20 ??~ 70 ??
Storage environment -40 ??~ 125 ??, <90%RH
Board size:2.72 x 3.980CM
Weight:13 grams
Application:
Home smart device image transmission
Wireless monitoring
Smart agriculture
QR wireless recognition
Wireless positioning system signal
And other IoT applications
Package Included:
1 x SP32-CAM with Bluetooth download module
1 x OV2640 camera module
