3S/4S/5S High Current Ternary Polymer Lithium Battery Protection Board 20A 40A
20A 3S 4S 5SLithium Battery Protection Board
FOR Li-POLYMER LiMnO Protect Parameter (3.6V / 3.7V)
Single Cell overcharge protect voltage:4.23-4.28V
Single Cell overcharge rotect recover voltage:4.08-4.18
overcharge protect delay:0.5-1.5S
Single Cell over-discharge protect voltage:2.72-2.88V
Single Cell over-discharge rotect recover voltage:2.9-3.1V
overcharge protect current:60A
over-discharge protect current:60A
over-discharge protectdelay:0.5-1.5S
temperature protect:YES
disconnect protect:YES
shortage protect:YES
shortage delay:100-600??S
shortage protect recover:YES
Charging current:25A
discharging current:25A
charging voltage:12.6V for 3S, 16.8V for 4S, 21V for 5S BMS board
Package included:
1 x 3S/4S/5S Lithium Battery Protection Board(not included 1S/2S)
Additional information
Weight | 0.015 kg |
---|---|
Number: No selection | 3S, 4S, 5S |
