Hobbyeagle A3 Super 2.0 II 3-Axis Gyro Flight Controller Stabilizer - 56%
/ 6-axis Gyro

Hobbyeagle A3 Super 2.0 II 3-Axis Gyro Flight Controller Stabilizer

SKUID:#3145

$188.06 $82.67

Save 56%
SKU: GBI353193 Category:

Shipping: in 2-7 business days.

Fast Delivery
100% Satisfaction
Buyer Protection
Secure Payment

General

  • Input Voltage : 4.8V – 7.4V
  • Type : 3-Axis Gyro Flight Controller Stabilizer
  • Operating Temp : -10 to 50 degrees
  • Main Controller : 32-bit MCU
  • Sensor : 3-axis gyroscope and 3-axis accelerometer
  • Size/Weight : Size: 43 * 27& * 14mm Weight: 10g (excluding wires)
  • Output Signal : PWM max frequency 333Hz, 1520±500uS
  • Accelerometer Scale Range : ±4g
  • Gyroscope Scale Range : ±2000 dps
  • Model : Hobbyeagle A3 Super 2.0 II
  • Input Signal : Standard PPM with center point 1520uS, or S.Bus serial data

Package Contents

  • 1 * USB Adapter (to connect stabilizer to PC for firmware updates and programming)
  • 1 * Data cable
  • 1 * Eagle A3 Super II Flight Stabilizer
  • 1 * Programming module with LCD display
  • 1 * 15cm male to male receiver cable
  • 2 * 15cm male to male 3-way receiver cables
    • Wiring Example (Aux Mode -3)The new A3 Super II has 7 separate input channels and 5 output channels. This gyro is compatible with standard receivers and single-line/bus type receivers such as Futaba’s S.Bus/S.Bus 2. Connect all the required channels between the controller and the receiver using the included 3-way male to male receiver cables. The flight stabilizer requires at least 3 receiver channels, up to 7 channels. The channels of AIL, ELE and RUD must be connected at all times otherwise the controller will not work.The A3 Super II has an integrated high precision 6-axis (3 gyro + 3 accelerometers) MEMS sensor with advanced attitude and PID control algorithm. The gyro can accurately detect the angular velocity and attitude of the aircraft and issue commands to all servos, which enables perfect balance and stability throughout the flight. The A3 Super II has built-in capabilities for delta-wing (flying-wing), v-tail, remote master gain adjustment, and separate dual aileron and elevator control. Finally, two of the most exciting new features on this gyro are the One-Click Rescue which allows you to return your plane to level flight at the flip of a switch (similar to Horizon’s SAFE technology) and the One-Click Hover which allows you to put your plane into a perfect hover at the flip of a switch.
