[4+32G] H96Max M1 Smart TV Box Android 13 Rockchip 3528 Quad 4K 8K Video Dual WIFI6 Set Top Box H.265 Bluetooth 4.0 Player
| System | ||||
| CPU | Quad Core ARM Cortex-A53 | |||
| GPU | Mali-450 | |||
| Memory | 4GB | |||
| Flash | 32GB | |||
| WiFi | WLAN 802.11a/b/g/n/ac | |||
| Bluetooth | BT 4.0 | |||
| I/O | 1*HD | 4K*2K UHD Output | ||
| 1*USB | 1*USB 2.0 | |||
| 1*IR Reciver | Remote Reciver Connect | |||
| 1*DC | 5V/2A | |||
| 1*AV | 480i/576i for CVBS | |||
| Software | ||||
| OS | Android 13.0 | |||
| Video | ??Video Decoder ??Real-time video decoder of MPEG-1, MPEG-2, MPEG-4 H.263, H.264/AVC, H.265/HEVC, MVC VC-1 AVS, AVS+,AVS2 ??MMU Embedded ??Supports frame timeout interrupt, frame finish interrupt and bit stream error interrupt ??Output data format YUV420 semi-planar, YUV400(monochrome), YUV422 is supported by H.264 ??H.264/AVC BP/MP/HP profile @ level 5.1; H.264/AVC MVC; up to 4Kx2K @ 60fps ??H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K @ 60fps ??AVS2 4KX2K @60fps ??MPEG-1, Main profile, up to 1080P @ 60fps ??MPEG-2, SP@ML, MP@HL, up to 1080P @ 60fps ??MPEG-4, ASP profile @ level 5, up to 1080P @ 60fps ??AVS, Jizhun profile @ level 6.0; up to 1080P @ 60fps ??AVS-P16 (AVS+), up to 1080P @ 60fps ??H.263, up to 576P @ 60fps ??VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P @ 60fps ??Video Encoder ??Support video encoder for H.264, HP@level4.2 ??H.264 maximum frame rate is up to 1920×1080 @60fps ??Capable of encoding HEVC Main Profile @ L4.1 High-tier ??H.265 resolution and frame rate are up to 1920×1080 @60fps ??JPEG encoder included ??JPEG decoder ??Input JPEG file:YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 sampling formats ??Output raw image:YCbCr 4:0:0, 4:2:0, 4:2:2, 4:4:0, 4:1:1 and 4:4:4 semi-planar ??Decoder size is from 48×48 to 8176×8176(66.8Mpixels) ??Support JPEG ROI(region of image) decode ??Maximum data rate is up to 76million pixels per second ??Video OUT ??Display Interface ??Support HD 2.0b output up to 4K 10bit @60Hz ??TV interface:TV encoder 10bit out for DAC ??HD interface: 24 bit (RGB888 YCbCr444), 30 bit(RGB101010,YCbCr 420, YCbCr 444) Max output resolution 4K for HD, 480i/576i for CVBS ??HD ??Compliant HD 2.0b ??Support YUV420 4k x 2k @ 60fps ??Support for 4k x 2k and 3D video formats ??Support for up to 10.2bps bandwidth ??Compliance HD compliance Test specification 1.4 and 2.x |
|||
| Audio | Supports MP3, AAC, WMA, RM, FLAC | |||
| Image | HD JPEG??BMP??GIF??PNG??TIF | |||
| Language | Multi-Language | |||
| Appliactions | ||||
| Online | Browse all video websites,support Netflix,Hulu,Youtube, etc. | |||
| Apps | Apps download freely form Google Play??Apkpure store etc. | |||
| Medium | Local Media playback,Support HDD, U Disck | |||
| Talk online | Support SKYPE ,MSN , facebook ,twitter ,QQ etc | |||
| Others | Support Email,office suit etc. Support DLNA function Support 2.4G wireless mouse/keyboard |
|||
| Packing | ||||
| Product dimension:96*96*16.8mm | ||||
| Unit products (G.W.):122g | ||||
| Unit packing:175*103*53mm | ||||
| Unit packing (G.W.):356.5g | ||||
| Accessories | ||||
| HD cable *1 | IR Remote *1 | User Manual *1 | Package box *1 | Power adapter *1 |
Additional information
| Weight | 0.4 kg |
|---|---|
| Plug: No selection | EU Plug, US Plug |
