HackRF One(1MHz-6GHz) Software Radio Platform SDR Development Board Open Source SDR Radio Platform
Features:
Wide Frequency Range:HackRF One operates in a wide frequency range from 1MHz to 6GHz, giving you incredible versatility for all types of RF exploration.
High Sample Rate:With a sample rate of up to 20 million samples per second, HackRF One can capture a wide spectrum of RF signals.
Open-Source Hardware:HackRF One is open-source hardware, designed to be used as a USB peripheral or standalone RF equipment.
Software Compatibility:HackRF One is compatible with a multitude of software like GNU Radio and SDR#, making it a flexible tool for all your needs.
Advanced Controls:The board has software-configurable RX and TX gain and baseband filters, software-controlled antenna port power, and convenient programming buttons.
USB-Powered:HackRF One is powered via USB 2.0, making it easy to use with any compatible device.
Specifications:
Operating Frequency:1 MHz to 6 GHz
Transceiver:half-duplex
Sample Rate:up to 20 million samples per second
Quadrature samples:8-bit I and 8-bit Q
Antenna Connector:SMA female
Clock Input and Output:SMA female
USB:Hi-Speed USB 2.0
Power Source:USB-powered
Package Includes:
1 x HackRF One (enclosed in an injection molded plastic enclosure)
1 x Micro USB Cable (100CM / 39 INCH)
1 x SMA Antenna
mso-bidi-font-family:’Times New Roman’;font-size:10.5000pt;mso-font-kerning:1.0000pt;’>
Additional information
Weight | 0.1 kg |
---|
