JumperRC T20S ExpressLRS ELRS 2.4GHz/915MHz Hall/RDC90 Sensor Gimbal Full Size EdgeTX Radio Transmitter for FPV RC Racer Drone Airplane Car Boat
JumperRC T20S ExpressLRS ELRS 2.4GHz/915MHz Hall/RDC90 Sensor Gimbal Full Size EdgeTX Radio Transmitter for FPV RC Racer Drone Airplane Car Boat
Please NOTE:Orders before August 7th, were shipped with the Unupgraded Version. And if you ordered after August 7th, you will receive the Upgraded Version, with the foldable antenna and upgraded gimbals as pictures shown, while the price is a little bit higher.
Desccription:
Brand:JumperRC
Model:T20S
MCU:STM32F407ZET6
Screen size:1.3′ OLED (resolution 128*64)
Voltage:6-8.4V
Rocker Stick Size:Standard
Gimbal size:Standard full size gimbal
Gimbal sensors:RDC90 / Hall (Optional)
Built-in RF:ELRS (915MHz/2.4GHz) (Optional)
Transmission power:max 1000mw
Antenna interface:SMA
External module interface:reserved (1.25mm-5P)
External module power supply:XT30 (2S2A output)
SD card:Chip-based internal (officially recommended by EdgeTX)
Working voltage:6-8.4v
Battery:21700*2 (not included)
Power Dutput:Maximum 1W
Size:185*188*68
Weight:448g (battery not included)
Package Included:
1x JumperRC T20 2.4GHz/915MHz ExpressLRS Transmitter
Additional information
Weight | 0.443 kg |
---|---|
Version: No selection | 2.4G RDC90+3pcs ELRS Receiver, 2.4G RDC90+JP4IN1 Micro Module, 2.4GHZ Hall Gimbal, 2.4GHz RDC90 Gimbal, 915M RDC90+3pcs ELRS Receiver, 915mHz Hall Gimbal, 915mHz RDC90 Gimbal |
