Orange Pi 5 8-core RK3588S Processor Module 4GB 8GB 16GB with External WiFi bluetooth Gigabit Ethernet Support NVME SSD Single Board
Specifications:
Main control chip:Rockchip RK3588S (8nm LP)
CPU:8-core 64-bit processor
4 Cortex-A7604 Cortex-A55,
The main frequency of the large core is 2.4GHz, and the main frequency of the small core is 1.8GHz
GPU:ARM Mali-G610
Built-in 3D GPU
OpenGL ES1.1/2.0/3.2. OpenCcL 2.2 Vulkan 1.2
NPU:Built-in AI accelerator NPU with up to 6 Tops computing power, supports INT4/INT8/INT16 mixed computing
PMU:RK806-1
RAM:4GB/8GB/16GB(LPDDR4/4x)
Storage:QSPI Nor FLASH 8MB
MicroSD (TF) Card
PCle M.2 M-KEY NVMe SSD
USB:USB3.0*1; USB2.0*2; Type-C (USB3.0) * 1
Video output:HDMI2.1, maximum support 8K@60Hz
DP1.4 (DisplayPort), DP1.45USB3.0, shared port with Type-C
2* MIPI D-PHY TX 4Lane, the maximum configuration can be 4K@60Hz
Camera:MIPI CSI 4Lane
2* MIPI D-PHY RX 4Lane
Audio:CODEC:ES8388
3.5mm headphone jack audio input/output
Input:Onboard MIC
HDMI 2.1 eARC
PCle M.2 M-KEY Socket:SSD solid state drive module supporting PCIe M.2 M-KEY NVMe
WI-FI6+BT5.0 custom module supporting PCIe M.2 M-KEY
Ethernet:10/100/1000Mbps Ethernet (YT8531B)
Expansion port:26Pin double-row pin, supports the following functions:
3*UART;6*PWM;2*I2C;1*SPI;2*CAN;17*GPIO;
These functions are multiplexed and cannot be supported at the same time
Keys:1* MaskROM key, 1* switch key, 1* RECOVERY key
Power supply:Support Type-C power supply (5V4A)
LED:Power Indicator:Red; Status Indicator:Green
Debug:3Pin debug serial port (UART)
Supported OS:Android12, Debian11
Product size:62mmx100mm
Weight:46g
Features:
1. Rockchip RK3588S octa-core 64-bit processor
2. Main frequency up to 2.4GHz
3. 4GB/8GB/16GB (LPDDR4/4x) memory
4. Support 8K video codec
Package Include:
1x Orange Pi 5 Single Board
