| Specification |
| Display |
Characteristic |
Full Screen |
| Touch Panel |
Support, 10-point Touch Control??Supported (Requires Separate Purchase), Active Pen With 4096-level Pressure Sensitivity, Original Handwriting, Compatible With Surface Pen |
| Screen Type |
Corning Gorilla Glass 5??IPS Technology |
| Screen Size |
10.1 Inches |
| Aspect Ratio |
16:10 |
| Screen Resolution |
Default:1920??1200??Maximum:2560??1600 |
| Pixels Per Inch |
299 PPI |
| CPU |
Product model |
AMD Ryzen 7 6800U |
| # of Performance-cores / # of Efficient-cores |
8C / 16T |
| Performance-core Max Turbo Frequency |
4.70 GHz |
| Efficient-core Max Turbo Frequency |
| Level 3 |
16 MB |
| Core Architecture |
Zen3+ |
| Lithography |
6nm |
| TDP |
15W-28W |
| GPU |
Graphics Card |
Integrated Graphics |
| Processor Graphics |
AMD Radeon 680M |
| Graphics Max Dynamic Frequency |
2.2 GHz |
| Execution Unit |
12CU |
| Shader |
768 |
| Video Memory |
Shared Memory |
| 4K Image resolution |
Supports |
| HDMI 2.1(TMDS) |
4096 x 2304 @60Hz |
| DP 1.4a |
7680 x 4320 @60Hz |
| eDP 1.4b |
4096 x 2304 @120Hz |
| DirectX |
DX12??DX12.1??DX 12 Ultimate |
| OpenGL |
4.6 |
| Storage |
Memory |
16GB |
| Memory Types |
LPDDR5-6400 MT/s |
| Memory Dual Channel |
Supports |
| Hard Disk Type |
M.2 SSD |
| Hard Disk Interface |
Socket 3 ?? 2 |
| Hard Disk Specifications |
1 ?? M.2??PCIe 4.0??NVMe 2280 SSD |
| 1 ?? M.2??PCIe 4.0??NVMe 2230 SSD |
| Standard Capacity |
M.2??PCIe 3.0??2280 SSD 1TB |
| Bus Specification |
PCIe 4.0 ?? 4 |
| Transfer Protocol |
NVMe 1.4 |
| Multimedia support |
Audio System |
Built-in Sound Chip + Intelligent Amplifier That Features High Energy Efficiency, High PSRR and Low Noise |
| Loudspeakers |
Built-in 4 Super Linear Speakers |
| Camera |
Built-in Camera:2 Million Pixels, Maximum Resolution:1612??1212, Super Wide-angle, High Refresh Rate |
| Microphone |
Built-in microphone |
| Network Communications |
Wi-Fi 6 |
IEEE 802.11 a/b/g/n/ac/ax, Support 2.4G/5G Dual Frequency Band, Dual Channel Maximum Transmission Rate 2402Mbps |
| MU-MIMO |
Supports |
| Bluetooth |
5.2 |
| I/O Interface |
Video / Data / Charging |
1 x USB4??40Gbps?? |
| 1 x USB 3.2 Gen 2 Type-C |
| 3 x USB 3.2 Gen 1 Type-A |
| HDMI 2.1 |
| microSDXC Slot |
Bus interface:UHS-I |
| Video Speed Class:V30 |
| Application Performance Class:A2, Read:160MB/s, Write:120MB/s |
| Compatible:microSDHC / microSDXC / microSDUC |
| SD Slot |
Bus interface:UHS-II |
| Video Speed Class:V90 |
| Read 312MB/s, Write:312MB/s |
| Compatible:SDHC/ SDXC/ SDUC |
| Audio Port |
1 x 3.5mm Headphone/Microphone Combo Interface, Compatible With Apple Headphones (US Specification) |
| BIOS Reset Port |
Supports |
| I/O |
Power |
Power Button With A Fingerprint Sensor |
| Keyboard |
QWERTY Keyboard Design, Backlight (2-level Brightness Control) |
| Indicator Lamp |
Charging Indicator, Running Indicator, CapsLook Indicator, Fan Switch Indicator |
| TouchPad |
Precision TouchPad ??PTP?? |
| Mouse |
The Joystick Simulates A Mouse, Requires Switching The Mode Handle/Mouse |
| Joystick |
Hall Sensor Sticks, Stepless, Super Linear, No Dead Zone, Sink-in Design, Native Support For Down Pressure Sensitive L3 / R3 |
| Game Accessories Buttons |
Analog Triggers |
| Game Function Buttons |
Double Silk-printed Legends (ABXY, ???????, Select, Start, Xbox (Menu)) |
| D-Pad |
Siamese Arrow Keys |
| Handle Vibration |
Double Vibration Motor |
| Sensor |
6-axis Gyroscope |
| Other Keys |
Handle/Mouse Switch Button??2 Custom Physical Buttons |
| Battery |
Battery Type |
Li-polymer |
| Battery Capacity |
67Wh |
| Battery Life |
3 Hours Of Heavy Use, 6-8 Hours Of Moderate Use, 14 Hours Of Light Use, Depending On The Specific Environment Of Use |
| Appearance |
Weight |
1005g |
| Size |
227 x 160 x 23 mm |
| Shell Material |
A and C Sides Are Made of 6061 Aluminummagnesium Alloy, LG-DOW 121H Aviation ABS |
| Shell Color |
Gun color |
| Covers |
Magnetic Suction Type, Can Be Stored Inside The Shell |
| Thermal Design |
Active Cooling, Big Fan + Dual Heat Pipe |
| Accessories |
Package Included |
GPD WIN Max 2 ?? 1 |
| 100W PD Power Adapter??20V==5A??20V==3.25A????1 |
| Supports 100W, c-c Power Cord With E-mark |
| Warranty Card ??1 |
| Product Manual ??1 |
| Warranty Information |
Warranty Policy |
Global Warranty |
| Warranty Time |
Device 1 year, Charger 1 year |
| Official Hotline |
+ 86 755 86572275 |
| Chinese Website |
www.Softwincn.com |
| English Website |
www.Gpd.hk |
