Atomstack M100 20W Quad Laser Module With Air Assist System

Atomstack M100 20W Quad Laser Module With Air Assist System
Description:
– The World’s First Quad-core Diode Laser
– 12mm Solid wood Cutting in One-PASS
– 8mm Acrylic Cutting in One-PASS
– It can even cut 0.05mm thin sheet metal
– Built-in Powerful air assist kit
Atomstack M100 fits the following models:
X7 Pro, X7 40W
A10 Pro, S10 Pro
A5 20W, A5 30W, A5 M30, A5 Pro, A5 M40, A5 Pro+, A5 M50, A5 M50 Pro
Features:
1. Equipped with air-assisted system, which is extremely helpful for cutting and engraving.
2. It works on all Atomstack frame-mounted models, just replace your old laser module.
3. Made of aluminum, strong and durable.
4. The laser head is equipped with a goggle piece that protects the user’s eyes while preventing pets from grabbing the laser dot.
5. Upgraded high quality fixed-focus laser, no need to focus.
6. Aviation aluminum TTL driver board with cooling fan can ensure continuous long time work.
7. Engraving speed is 200% higher than other 10W lasers.
8. The laser sintering temperature is 2400 degrees, the effect of engraving metal is better.
9. The wind-collecting hood can clean the smoke and dust to protect the lens to avoid laser energy attenuation.
Specification:
Brand:Atomstack
Model:M100
Machine Power:130W
Laser Power:20W
Product Material:Aluminum 6061 Anode
Housing Size:140*65*60mm
Circuit Board Size:44*52mm
Circuit Board:V/PWM Modulation Board
Wire Rod:22# 2P2.54 Terminal Reverse Wire 80mm
Optical Lens:??6/glass
Fan:24V
Laser Beam Mode:Spot
Working Mode:Pulse Work
Lightspot Size:0.08*0.1mm
Working Time:10000H
Working Temperature:0??~70??
Storage Temperature:-40??~85??
Sintering Temperature:2000~2400??
Product Net Weight:715g
CAUTIONS:
1. The laser light emitted by the laser module is likely to injure persons’eye, so do not directly gaze its end surface and wear appropriate safety glasses to prevent laser light when it is working.
2. Laser module needs an appropriate laser driver(PCB). When the laser module connects with power supply, please set the output voltage to zero. The adjustment of the current should be slowly increased or decrease to avoid damaging the device.
3. Keep the device working or storing in a dry environment. The anti-dust grade is over one million, in order to prevent dust inside the lens to affect the laser dot shape.
4. Working at high temperatures will increase the threshold current, reduce conversion efficiency and speed up the aging of the device.
5. When output power is higher than it’s specific parameter of operation, it will accelerate the aging of the device.
6. When the operation temperature of the laser diode is over 70degree, please do well heat dissipation of it.
7. This laser module is an electrostatic sensitive device. Please make sure ground yourself or wear an antistatic wrist strap before you take it.
Package Included:
1 x M100 Laser Module
1 x PCB Circuit Board
1 x Compatible Plate??A5 series and 10W series use different adapter boards, please pay attention to the distinction??
1 xFixed Focus Plate
1xConnection Line
1 xWrench
6 x Screws
1 x Power Supply
1 x Air assist kit
Details:

Additional information
