300Mbps 2.4G Wireless Wifi Repeater AP Router Dual Antenna Signal Booster Extender Amplifier

300Mbps 2.4G Wireless Wifi Repeater AP Router Dual Antenna Signal Booster Extender Amplifier
Features:
1. Provide a 10/100M Ethernet (WAN) interface for XDSL modem/ Cable modem/ Ethernet.
2. Support wireless transmission rate up to 300Mbps, with rate adaptation function, automatically adjust wireless transmission rate.
3. Networked static IP, dynamic IP, PPPOE dialing, wireless relay.
4. Support encryption and security mechanisms such as WPA/WPA2, WPA-PSK/WPA2-PSK.
5. Adopt seamless roaming technology to ensure efficient wireless connection.
6. Built-in network address translation (NAT function, support for virtual servers, special applications and DMZ hosts.
7. Built-in DHCP server and static address allocation at the same time.
8. Support Universal Plug and Play (UPNP), data conforming to UPNP standard can pass smoothly.
9. Support QoS bandwidth control function, which can effectively allocate the download rate of the client.
10. Support dynamic DNS function, able to provide domain name service for dynamic IP address.
11. Built-in static routing function, you can build a special network topology as needed.
12. Support wired to wireless, wireless to wireless, wireless to wired.
13. In the routing mode, the port is the WAN port input, and in the relay mode, the port is the LAN port output.
14. Full English configuration interface with easy installation wizard (Wizard).
15. Support Chinese, English, Russian, Spanish, Italian, German, Japanese, French, Portuguese, Arabic, etc. to switch freely.
16. PC and mobile phone settings page automatically adapts automatically.
17. When there is no network, it will automatically enter the WEB setting page and access the Internet in three steps.
Specifications:
Model:ZT-RX21W-C3
Type:Wireless
Chip:MT7628NN
SPI Flash:8M (maximum support for 16M)
SDRam:32M
Maximum data rate:300Mbps
Standards and Protocols:IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u,
Frequency range:2.4-2.4835 GHz
RF power:19dBm (Max)
2.4G Wi-Fi Transmission Rate:300 Mbps
Wi-Fi Transmission Standard:802.11n
Wired Transfer Rate:10/100 Mbps
Interface:WAN/LAN:1 x 10/100M RJ45 Ports (Auto MDI/MDIX)
Button:Reset
Distance:Outdoors 300m, Indoor 100m (According to the Actual Environment Change)
Antenna:2*3.5dBi antenna(Rotatable 180??)
Size:100*85*45mm/3.9’x3.3’x1.8′
Voltage:110-240V
Color:White
Operating Temperature:0oC~40oC
Storage Temperature:-40??~70??
Relative Humidity (Operational):10%~90% , noncondensing
Relative Humidity (Storage):5%~95% , noncondensing
System requirements:
* WLAN access point/client according to IEEE 802.11n, g, b
* 110 ~ 230 volt socket
The WLAN client must support at least the WPA eccyption standard.
WLAN access point and the WLAN client with automatic IP address assignment(DHCP)
Forwarding of IPv4-based protocols/ Address Resolution Protocol
The network name(SSID) of the WLAN access point must be set to ‘visible’
Package Included:
1 x Wireless Wifi Extender Repeater ( US/EU/UK/AU Plug)
1 x RJ-45 Networking Cable
1 x User Manual
Note:
1. Make sure the repeater is placed in a location where it can receive a strong signal from your desired wireless Internet connection. The repeater will not work without a signal that it can repeat
2. The wireless signal rate based on the IEEE 802.11b chipset standard, g, n used. Actual flow may vary. Network conditions and environmental factors reduce the actual flow. All specifications are subject to change without notice.
3. Please allow 0.5-1cm differences due to manual measurement.
4. Due to the light and screen difference, the item’s color may be slightly different from the pictures.
