GUUDGO Wireless 433Mhz PIR Motion Sensor Low power consumption 110 Degree Wide Angle for Alarm System
Features:
Wireless transmitting digital signal
Low power indication
Automatic temperature compensation
SMT adopted, anti-RFI & anti-EMI
Adjustable detecting distance
Detection range can reach up to 12m
Specification:
Working voltage:DC 3V (2 x1.5V AAA batteries) (The Battery not included )
Quiescent current:60uA
Alarm current:20mA
Detection distance:8 ~ 12m
Detection angle:110 degrees
Radio frequency:433MHz
Radio distance:30m (with walls), 150m (without walls, in open areas)
Sensor:dual-element infrared sensor
Working temperature:-10C~ +50C
Detection method:PIR
Size:102 x 53 x 38mm
Package Included:
1 x 433Mhz PIR Motion Sensor
Additional information
| Weight | 0.06 kg |
|---|
