DJI Mini SE 4KM FPV with 2.7K Camera 3-Axis Gimbal 30mins Flight Time 249g Vision Sensor GPS Hover RC Drone Quadcopter RTF
DJI Mini SE 4KM FPV with 2.7K Camera 3-Axis Gimbal 30mins Flight Time 249g Vision Sensor GPS Hover RC Drone Quadcopter RTF
Specifications:
| Aircraft | Takeoff Weight | < 249 g |
| Dimensions | Folded:138?G81?G58 mm (L?GW?GH) Unfolded:159?G203?G56 mm (L?GW?GH) Unfolded (with propellers):245?G289?G56 mm (L?GW?GH) |
|
| Diagonal Distance (propellers excluded) | 213 mm | |
| Max Ascension Speed | 4 m/s (S Mode) 2 m/s (P Mode) 1.5 m/s (C Mode) |
|
| Max Descent Speed | 3 m/s (S Mode) 1.8 m/s (P Mode) 1 m/s (C Mode) |
|
| Max Speed (near sea level, no wind) |
13 m/s (S Mode) 8 m/s (P Mode) 4 m/s (C Mode) |
|
| Maximum Takeoff Altitude | 3000 m | |
| Max Flying Time | 30 minutes (measured while flying at 17 kph in windless conditions) | |
| Max Wind Speed Resistance | 8.5 m/s to 10.5m/s (Scale 5) | |
| Max Tilt Angle | 30?? (S Mode) 20?? (P Mode) 20?? (C Mode) |
|
| Max Angular Vellocity | 150??/s (S Mode) 130??/s (P Mode) 30??/s (C Mode) |
|
| Operating Temperature Range | 0?? to 40??C (32?? to 104??F) | |
| Operating Frequency | Model MT2SS5:5.725-5.850 GHz Model MT2SD25:2.400-2.4835 GHz, 5.725-5.850 GHz |
|
| Transmitter Power (EIRP) | Model MT2SS5 5.8 GHz:<30 dBm (FCC); <28 dBm (SRRC) Model MT2SD25 2.4 GHz:<19 dBm (MIC/CE) 5.8 GHz:<14 dBm (CE) |
|
| GNSS | GPS+GLONASS | |
| Hover Accuracy Ran-ge | Vertical:?I0.1 m (with Vision Positioning), ?I0.5 m (with GPS Positioning) Horizontal:?I0.3 m (with Vision Positioning), ?I1.5 m (with GPS Positioning) |
|
| Gimbal | Mechanical Range | Tilt:-110?? to 35?? Roll:-35?? to 35?? Pan:-20?? to 20?? |
| Controllable Range | Tilt:-90?? to 0?? (default setting) -90?? to +20?? (extended) | |
| Stabilization | 3axis (tilt, roll, pan) | |
| Max Control Speed (tilt) | 120??/s | |
| Angular Vibration Range | ?I0.01?? | |
| Sensing System | Downward | Operating Ran-ge:0.5-10 m |
| Operating Environment | Non-reflective, discernable surfaces Diffuse reflectivity (>20%) Adequate lighting (lux>15) |
|
| Camera | Sensor | 1/2.3?? CMOS Effective Pixels:12 MP |
| Lens | FOV:83?? 35 mm Format Equivalent:24 mm Aperture:f/2.8 Shooting Range:1 m to ?? |
|
| ISO Range | Video: 100-3200 (Auto) 100-3200 (Manual) Photo: 100-3200 (Auto) 100-3200 (Manual) |
|
| Shutter Speed | Electronic Shutter:4-1/8000s | |
| Still Image Size | 4:3:4000?G3000 16:9:4000?G2250 |
|
| Still Photography Modes | Single shot Interval:2/3/5/7/10/15/20/30/60 s |
|
| Video Resolution | 2.7 K:2720?G1530 24/25/30 p FHD:1920?G1080 24/25/30/48/50/60 p |
|
| Max Video Bitrate | 40 Mbps | |
| Supported File Systems | FAT32 (?P32 GB) exFAT (>32 GB) |
|
| Photo Format | JPEG | |
| Video Format | MP4 (H.264/MPEG-4 AVC) | |
| Remote Controller & Video Transmission |
Operating Frequency | Model MR1SS5:5.725-5.850 GHz Model MR1SD25:2.400-2.4835 GHz, 5.725-5.850 GHz |
| Max Transmission Distance (unobstructed, free of interference) |
Model MR1SS5 5.8 GHz:4000 m (FCC); 2500 m (SRRC) Model MR1SD25 2.4 GHz:2000 m (MIC/CE) 5.8 GHz:500m (CE) |
|
| Operating Temperature Range | 0?? to 40??C (32?? to 104??F) | |
| Transmitter Power (EIRP) | Model MR1SS5 5.8 GHz:<30 dBm (FCC); <28 dBm (SRRC) Model MR1SD25 2.4 GHz:<19 dBm (MIC/CE) 5.8 GHz:<14 dBm (CE) |
|
| Battery Capacity | 2600 mAh | |
| Operating Current/Voltage | 1200 mA 3.6 V (Android) 450 mA 3.6 V (iOS) |
|
| Supported Mobile Device Size | Max length:160 mm Max thickness:6.5-8.5 mm |
|
| Supported USB Port Types | Lighting, Micro USB (Type-B), USB Type-C | |
| Video Transmission System | Enhanced Wi-Fi | |
| Live View Quality | 720p/30fps | |
| Max. Bitrate | 4 Mbps | |
| Latency (depending on environmental conditions and mobile device) |
170-240 ms | |
| Intelligent Flight Battery | Capacity | 2250 mAh |
| Voltage | 7.7 V | |
| Max Charging Voltage | 8.8 V | |
| Battery Type | LiPo 2S | |
| Energy | 17.32 Wh | |
| Net Weight | 82.5 g | |
| Max Charging Power | 29 W | |
| Charging Temperature Ran-ge | 5?? to 40??C (41?? to 104??F) | |
| Charger | Input | 100-240 V, 50/60 Hz, 0.5A |
| Output | 12V 1.5 A / 9V 2A / 5V 3A | |
| Rated Power | 18 W | |
| APP | Name | DJI Fly |
| Required Operating System | iOS v10.0 or later Android v6.0 or later | |
| Supported SD Cards | Supported SD Cards | UHS-I Speed Class 3 or above is required. A list of reccomended microSD cards can be found below |
Features:
– < 249g Ultralight
– 30-mins Max Flying Time
– 4KM HD Video Transmission
– Vision Sensor + GPS Precise Hover
– 3-Axis Gimbal 2.7K Camera
– Simplified Recording & Editing
Package Included:
Mini SE:
1 x Aircraft
1 x Remote Controller
1 x Intelligent Flight Battery
1 x Pair of Spare Propellers
1 x USB Cable
1 x Gimbal Protector
3 x RC Cable (USB/USB-C/Lighting/)
1 x Pair of Spare Control Sticks
6 x Spare Screw
1 x Screwdriver
Mini SE Fly More Combo:
1 x Aircraft
1 x Remote Controller
3 x Intelligent Flight Battery
3 x Pair of Spare Propellers
2 x USB Cable
1 x Gimbal Protector
3 x RC Cable (USB/USB-C/Lighting/)
1 x Pair of Spare Control Sticks
18 x Spare Screw
1 x Screwdriver
1 x Two-Way Charging Hub
1 x Carrying Bag
Additional information
| Weight | 1.2 kg |
|---|---|
| Mode: No selection | DJI Mini SE, DJI Mini SE Fly More Combo |
