Machifit DC 12V Linear Actuator 50mm Stroke 100/200/300/500/700/1000N Linear Drive Electric Motor Controller
Features:
– [Built-in limit switches]:Self-locking function. The telescopic rod will automatically stop when it reaches the top/bottom. Make sure the motor will not burn empty.
– [Stop Anywhere]:Cut off the power, it can be stop at any position, with machine lock, safe and secure.
– [Metal gears]:powder alchemy technology, pure metal gears, double strength and toughness.
– [Aluminum Alloy Material]:IP54 protection, is a power unit. The surface has undergone 27 polishing processes, and the structure design is tight.
– [Low Resistance More Power-Saving]:the wire uses oxygen-free pure copper as the conductor, low resistance, durable and safe to use.
Specification:
| Material | Aluminum alloy |
| Input Voltage | DC 12V |
| Rated power | 20W, Max. 30W |
| Ambient temperature | -20??C to + 75??C |
| Standard protection class | IP54 |
| Noise level | Less than 42dB |
| Stroke length | 50mm / 2inch |
| Retracted length | 155mm |
| Extended length | 205mm |
| Options | 100N 90mm per second / 150N 70mm per second / 180N 50mm per second / 200N 40mm per second / 230N 25mm per second / 250N 15mm per second / 300N 30mm per second / 500N 20mm per second / 700N 10mm per second / 1000N 5mm per second(optional) |
| Quantity | 1pc |
Force And Speed:
100N0kg / 150N5kg /180N8kg / 200N0kg /
230N3kg / 250N5kg / 300N0kg / 500N0kg /
700N0kg / 1000N00kg
If you would like other stroke, please click to check:
50mm Stroke ID:1856841
100mm Stroke ID:1856938
150mm Stroke ID:1856986
200mm Stroke ID:1856992
250mm Stroke ID:1857010
Produce Included:
| 1 x | 12V Linear Actuator |
More Detail:
Additional information
| Weight | 1.2 kg |
|---|---|
| Speed: No selection | 1000N 5mm per second, 100N 90mm per second, 150N 70mm per second, 180N 50mm per second, 200N 40mm per second, 230N 25mm per second, 250N 15mm per second, 300N 30mm per second, 500N 20mm per second, 700N 10mm per second |
